Corner LED Channel | 45 Degree V Shape Profile | DENO

45 degree V shape LED channels in 10x10mm, 13x13mm and 16x16mm for under cabinet, wardrobe and stair lighting. Aims light onto the worktop, hides the diodes.

Corner LED Channel models & key specifications (4)

DL-1616 HX-V — 2835 · 120 LEDs/m · 24V

DL-1616 HX-V Corner LED Channel — 24V, cuttable every 35.7mm, 6mm FPCB width, 2835 LEDs, 120 LEDs/m

LED Type: 2835 · LED Density: 120leds/m or above · Voltage: DC 24V · Cutting Unit: 6LEDs/35.71mm · PCB Width: 6mm · Copper Foil: 3oz · Circuit Type: CV

DL-1010HX-V — 1515 · 120 LEDs/m · 24V

DL-1010HX-V Corner LED Channel — 24V, cuttable every 3.3mm, 5mm FPCB width, 1515 LEDs, 120 LEDs/m

LED Type: 1515 · LED Density: 120leds/m or above · Voltage: DC 24V · Cutting Unit: 1LED/3.333mm · PCB Width: 5mm · Copper Foil: 2oz · Circuit Type: CV

DL-1313HX-M — 2216 · 120 LEDs/m · 24V

DL-1313HX-M Corner LED Channel — 24V, cuttable every 50mm, 8mm FPCB width, 2216 LEDs, 120 LEDs/m

LED Type: 2216 · LED Density: 120leds/m or above · Voltage: DC 24V · Cutting Unit: 12LEDs/50mm · PCB Width: 8mm · Copper Foil: 3oz · Circuit Type: CV

DL-1313 HX-V — 2216 · 120 LEDs/m · 24V

DL-1313 HX-V Corner LED Channel — 24V, cuttable every 25mm, 5mm FPCB width, 2216 LEDs, 120 LEDs/m

LED Type: 2216 · LED Density: 120leds/m or above · Voltage: DC 24V · Cutting Unit: 6LEDs/25mm · PCB Width: 5mm · Copper Foil: 2oz · Circuit Type: CV

Corner & V Shape LED Channel — Buyer Questions

What is a V shape LED channel?

A V shape LED channel is a corner extrusion with a 45 degree back, so it seats into the internal angle where two surfaces meet and throws light diagonally across the opening. DENO offers 10x10mm, 13x13mm and 16x16mm bodies — the standard way to light a cabinet interior, a shelf underside or a stair nosing without the fitting ever being in the sightline.

Which channel is best for under cabinet LED lighting?

A 45 degree corner body mounted at the front edge of the wall unit. It aims the beam onto the worktop instead of into the room, hides the diode line from anyone standing at the counter, and keeps the tape off the underside where steam and grease collect. The 16x16mm body suits full-depth kitchen units; 10x10mm suits shallow shelves and wine cabinets.

Can a corner LED extrusion be cut to exact cabinet lengths?

Yes, and the strip matters as much as the bar. The 10x10mm corner channel is matched to a 1515 tape with a 3.333mm cutting unit, so the LED line can be trimmed at every single LED and still light the full width of a wardrobe or drawer. Cut the aluminum with a fine-tooth blade, deburr, then refit the end cap.

Is there a magnetic corner profile for cabinets?

The 13x13mm magnetic cabinet body combines both ideas: a corner-friendly section with magnets in the base, so it can be repositioned inside a steel-framed display cabinet or wardrobe as shelves move. Where the carcass is timber, add a steel plate along the mounting line.

What diffuser should a wardrobe or closet LED profile use?

Frosted, in almost every case. Inside a wardrobe the eye is close to the fitting, so a clear cover shows every die and glares off hanging rails, while a frosted PC cover trades roughly 8–12% of the lumens for an even line. Choose opal only where the sightline is direct and the run is short.
