LED Wall Washer Strip | DENO LED Strip Manufacturer

DENO LED's LED wall washer strip series offers five distinct models, engineered for uniform vertical surface illumination. These 24V LED strip lights feature high CRI (Ra>90) for accurate color rendering and are available with power densities ranging from 10W/m to 24W/m. Designed for architectural and commercial applications requiring precise, consistent lighting, they support various IP ratings and custom lengths, ensuring suitability for diverse indoor and outdoor installations.

Single Color models & key specifications (5)

16006 — 3030 · 24 LEDs/m · 24V

16006 Single Color — 24V, cuttable every 270mm, 15mm FPCB width, 3030 LEDs, 24 LEDs/m

LED Type: 3030 · LED Density: 24 · Voltage: 24V · Cutting Unit: 6LEDs/270mm · PCB Width: 15mm · Copper Foil: 2oz · Circuit Type: CC

1242 — 3030 · 48 LEDs/m · 24V

1242 Single Color — 24V, cuttable every 41.6mm, 12mm FPCB width, 3030 LEDs, 48 LEDs/m

LED Type: 3030 · LED Density: 48 · Voltage: 24V · Power: 2.8~28.8W · Cutting Unit: 2LEDs/41.6mm · PCB Width: 12mm · Copper Foil: 3oz · Circuit Type: CV

15215 — 3030 · 24 LEDs/m · 24V

15215 Single Color — 24V, cuttable every 125mm, 15mm FPCB width, 3030 LEDs, 24 LEDs/m

LED Type: 3030 · LED Density: 24 · Voltage: DC24V · Cutting Unit: 3LEDs/125mm · PCB Width: 15mm · Copper Foil: 2oz · Circuit Type: CV

1241 — 3030 · 48 LEDs/m · 24V

1241 Single Color — 24V, cuttable every 41.6mm, 12mm FPCB width, 3030 LEDs, 48 LEDs/m

LED Type: 3030 · LED Density: 48 · Voltage: 24V · Power: 2.8~28.8W · Cutting Unit: 2LEDs/41.6mm · PCB Width: 12mm · Copper Foil: 3oz · Circuit Type: CV

10461 — 3030 · 18 LEDs/m · 24V

10461 Single Color — 24V, cuttable every 166.7mm, 24mm FPCB width, 3030 LEDs, 18 LEDs/m, IP20

LED Type: 3030 · LED Density: 18 · Voltage: 24V · Cutting Unit: 3LEDs/166.66mm · PCB Width: 24 · Copper Foil: 2oz · Circuit Type: CC · IP Rating: IP20

Frequently asked questions

What distinguishes DENO LED's LED wall washer strip from standard LED strip lights?

DENO LED's LED wall washer strip is specifically designed for uniform vertical illumination, minimizing hotspots and ensuring consistent light distribution across surfaces. This is achieved through optimized LED placement and optical design, differentiating it from general-purpose LED strip lights that may produce uneven light fields when used for wall washing.

What are the typical power and voltage specifications for your LED wall washer strip models?

Our LED wall washer strip models operate at 24V DC, with power densities ranging from 10W/m to 24W/m. This voltage provides a balance between efficiency and manageable voltage drop over typical installation lengths. Specific power consumption varies by model and LED density.

Can DENO LED provide custom lengths or specific IP ratings for the LED wall washer strip?

Yes, as an OEM/ODM manufacturer, DENO LED offers custom lengths for our LED wall washer strip products to meet project-specific requirements. We also provide various IP ratings, including IP20, IP65, and IP67, to ensure suitability for both indoor and outdoor environments. Customization is a core service.

What is the minimum bending radius for DENO LED's LED wall washer strip?

The minimum bending radius for DENO LED's LED wall washer strip varies by specific model and its construction, particularly the FPCB type and encapsulation. Generally, a minimum bending radius of 20-30mm is recommended to prevent damage to the FPCB and LED components. Consult individual product datasheets for precise specifications.
