Single-Color SOB LED Strip Light (#13922)
8mm · 24V · 20cut
Model: 13922
Overview
The DENO LED model 13922 is an 8mm, 24V single-color SOB LED strip offering dot-free lighting with an impressive 180° beam angle. Its unique design provides exceptional flexibility and strong bending resistance, featuring a built-in bracket for uniform temperature distribution and superior heat dissipation thanks to its double-layer PCB. With customization options for CCT, higher CRI, and power, this series is a stable, mature linear lighting solution known for excellent co...
Description
This single-color SOB LED strip light delivers continuous dot-free linear illumination with an expansive 160-degree beam angle and exceptional color consistency. Engineered with a 2oz double-layer copper PCB and built-in bracket design, the 8mm strip ensures efficient heat dissipation and strong bending resistance. Operating on 24V constant voltage, the dimmable tape features 350 LEDs per meter and precise cutting increments every 20mm for flexible installations. Tailored for display lighting and decorative accents, we provide OEM custom CCT and power configurations for wholesale project supply requirements.
Specifications
| LED QTY | 350LEDs/m |
|---|---|
| PART NO | DL-FSOBA175V24-13922-* |
| SMD TYPE | SOB |
| CUTTABLE UNIT | 7LEDs/20mm |
| DIMMABLE | Yes |
| IP RATING | IP20 |
| LED PITCH | 2.857mm |
| PCB WIDTH | 8 |
| BEAM ANGLE | 160° |
| RUN LENGTH | 5m |
| COPPER FOIL | 2oz |
| ON OFF TIMES | 10000（test times） |
| POWER RANGE | 6~24W |
| CIRCUIT TYPE | C.V. (Resistor Based) |
| INPUT VOLTAGE | 24V |
| MIN BEND DIAMETER | Φ60mm |
| OPERATING TEMPERATURE | -25~40°C; Tc: 75°C (max) |
Applications
- Cove, wall-wash & perimeter lighting — Coves, recesses, wall-wash details and ceiling perimeters where a continuous, uniform line of light is required.
- Showroom & hospitality display lighting — Shelving, display cases, reception desks and signage backlighting in shops, showrooms and hospitality spaces.
- Kitchen & wardrobe under-cabinet lighting — Kitchen, wardrobe and furniture task lighting where the strip stays hidden and only the light is seen.
Recommended accessories & compatible parts
- DL-1215 — 12x15mm Surface Mount LED Channel — Tall U Shape Aluminum Profile: Accepts LED strips up to 8mm wide.
- DL-1313HX-M — 13x13mm Magnetic Cabinet LED Channel — Tool-Free Corner Aluminum Profile: Accepts LED strips up to 8mm wide.
- DL-1408 HX — 14x8mm Surface Mount LED Channel — Slim Aluminum Profile for 8mm Strip: Accepts LED strips up to 8mm wide.
- DN-PSU-100 — 24V 100W Class-2 LED Driver · High Efficiency: Matches the 24V DC input of this strip; size the driver with at least 20% headroom over total load.
- DN-PSU-150 — 24V 150W Class-2 LED Driver · Premium: Matches the 24V DC input of this strip; size the driver with at least 20% headroom over total load.
- DN-PSU-60 — 24V 60W Class-2 LED Driver · Constant Voltage: Matches the 24V DC input of this strip; size the driver with at least 20% headroom over total load.
- V1 — 5-36VDC 1-Channel * 8A RF+Push Dimming Controller | V1: Matched by input voltage range and colour channels.
Request a quotation for #13922
DENO LED is a Shenzhen-based LED strip manufacturer with its own Foshan production base. Send the run length, voltage, CCT/CRI and IP rating you need and our engineering team replies with a specification sheet, wiring plan and price — OEM/ODM and fully custom builds included.
- Warranty: 5 years
- Lead time: standard boards: samples from 1 working day · custom: 3–5 working days · new FPCB: 1–3 weeks · production 1–2 weeks after sample approval
- Compliance: CE · UL · RoHS
- Bonding wire: 99.99% pure gold
- Copper foil: 99.9% pure copper FPCB
Photometric Performance — CCT × CRI Efficacy Matrix
Peak measured luminous efficacy: 132.8 lm/W at 4000K, Ra 90, ErP energy class E (Grade DL (2nd Tier) · 9W/m).
All values are measured at the stated power density and ambient 25 °C, reported as luminous efficacy in lumens per watt (lm/W), luminous flux per metre (lm/m) and the corresponding EU ErP (2019/2015) energy class.
Grade DL (2nd Tier) · 9W/m
| CCT (K) | Ra 80 — Luminous Efficacy (lm/W) | Ra 80 — Luminous Flux (lm/m) | Ra 80 — ErP Energy Class | Ra 90 — Luminous Efficacy (lm/W) | Ra 90 — Luminous Flux (lm/m) | Ra 90 — ErP Energy Class | Full Spectrum (Ra 95+) — Luminous Efficacy (lm/W) | Full Spectrum (Ra 95+) — Luminous Flux (lm/m) | Full Spectrum (Ra 95+) — ErP Energy Class |
|---|---|---|---|---|---|---|---|---|---|
| 1800 K | — | — | — | 100.4 lm/W | 904 lm/m | F | — | — | — |
| 2300 K | — | — | — | 111.9 lm/W | 1007.4 lm/m | E | — | — | — |
| 2700 K | — | — | — | 121.1 lm/W | 1090.2 lm/m | E | 98.1 lm/W | 883.3 lm/m | F |
| 3000 K | — | — | — | 127.5 lm/W | 1147.6 lm/m | E | 103.7 lm/W | 933.1 lm/m | F |
| 3500 K | — | — | — | 129.7 lm/W | 1167.4 lm/m | E | 106.8 lm/W | 961.4 lm/m | F |
| 4000 K | — | — | — | 132.8 lm/W | 1195.6 lm/m | E | 109.6 lm/W | 986.8 lm/m | F |
| 5000 K | — | — | — | 132.7 lm/W | 1194.6 lm/m | E | — | — | — |
| 6500 K | — | — | — | 127.4 lm/W | 1146.7 lm/m | E | — | — | — |
Grade DL (2nd Tier) · 12W/m
| CCT (K) | Ra 80 — Luminous Efficacy (lm/W) | Ra 80 — Luminous Flux (lm/m) | Ra 80 — ErP Energy Class | Ra 90 — Luminous Efficacy (lm/W) | Ra 90 — Luminous Flux (lm/m) | Ra 90 — ErP Energy Class | Full Spectrum (Ra 95+) — Luminous Efficacy (lm/W) | Full Spectrum (Ra 95+) — Luminous Flux (lm/m) | Full Spectrum (Ra 95+) — ErP Energy Class |
|---|---|---|---|---|---|---|---|---|---|
| 1800 K | — | — | — | 98.3 lm/W | 1180.2 lm/m | F | — | — | — |
| 2300 K | — | — | — | 109.6 lm/W | 1315.2 lm/m | F | — | — | — |
| 2700 K | — | — | — | 118.6 lm/W | 1423.3 lm/m | E | 96.1 lm/W | 1153.1 lm/m | F |
| 3000 K | — | — | — | 124.9 lm/W | 1498.2 lm/m | E | 101.5 lm/W | 1218.2 lm/m | F |
| 3500 K | — | — | — | 127 lm/W | 1524 lm/m | E | 104.6 lm/W | 1255.1 lm/m | F |
| 4000 K | — | — | — | 130.1 lm/W | 1560.9 lm/m | E | 107.4 lm/W | 1288.2 lm/m | F |
| 5000 K | — | — | — | 130 lm/W | 1559.6 lm/m | E | — | — | — |
| 6500 K | — | — | — | 124.8 lm/W | 1497 lm/m | E | — | — | — |
Grade DL (2nd Tier) · 18W/m
| CCT (K) | Ra 80 — Luminous Efficacy (lm/W) | Ra 80 — Luminous Flux (lm/m) | Ra 80 — ErP Energy Class | Ra 90 — Luminous Efficacy (lm/W) | Ra 90 — Luminous Flux (lm/m) | Ra 90 — ErP Energy Class | Full Spectrum (Ra 95+) — Luminous Efficacy (lm/W) | Full Spectrum (Ra 95+) — Luminous Flux (lm/m) | Full Spectrum (Ra 95+) — ErP Energy Class |
|---|---|---|---|---|---|---|---|---|---|
| 1800 K | — | — | — | 94.3 lm/W | 1697.2 lm/m | F | — | — | — |
| 2300 K | — | — | — | 105.1 lm/W | 1891.4 lm/m | F | — | — | — |
| 2700 K | — | — | — | 113.7 lm/W | 2046.9 lm/m | E | 92.1 lm/W | 1658.3 lm/m | F |
| 3000 K | — | — | — | 119.7 lm/W | 2154.6 lm/m | E | 97.3 lm/W | 1751.9 lm/m | F |
| 3500 K | — | — | — | 121.8 lm/W | 2191.7 lm/m | E | 100.3 lm/W | 1804.9 lm/m | F |
| 4000 K | — | — | — | 124.7 lm/W | 2244.7 lm/m | E | 102.9 lm/W | 1852.6 lm/m | F |
| 5000 K | — | — | — | 124.6 lm/W | 2242.9 lm/m | E | — | — | — |
| 6500 K | — | — | — | 119.6 lm/W | 2152.8 lm/m | E | — | — | — |
Related models in this series
- SOB High Density LED Strip Light (#16662)
- Ultra Narrow SOB LED Strip Light (#16416)
- SOB Flexible Linear Light (#16614)
- Green light Flexible LED Strip Light (#8215-G)
- Ice Blue Flexible LED Strip Light (#8215-IB)
- High Efficiency SOB LED Strip Light (#16791)
- Single-Color SOB LED Strip Light (#11236)
- SOB High Density LED Strip Light (#17000)
See every model in SOB LED Strip Series or narrow to Sob Classic. Compare wattage, lumen output and run length in the ProCalc parameter library, or request OEM/ODM pricing on the custom manufacturing page.
Frequently Asked Questions
What is the beam angle and is this SOB LED strip truly dot-free?
This SOB LED strip features an ultra-wide 180° beam angle. Its design ensures completely dot-free and uniform light distribution for smooth illumination.
What are the power and voltage specifications for the 13922 model?
The 13922 model operates at 24V input voltage with a flexible power range of 6W to 24W, providing versatile application options.
Can DENO LED provide customization options for this product series?
Yes, we offer flexible customization for this series, including special CCTs, higher CRI values, and different power outputs to meet specific project needs.
What are the suitable applications for the 13922 SOB LED strip?
The 13922 SOB LED strip is ideal for decorative projects, display cases, prop lighting, and other applications requiring consistent and flexible linear illumination.
Is this SOB strip light also called FOB, S-COB or COB Pro strip light?
Yes. Model 13922 belongs to the DENO SOB (Spot on Board) family, which the market also calls FOB strip light, S-COB strip light or COB Pro strip light. All three names describe the same dot-free chip-on-board LED strip construction, so you can quote it under whichever term your project specification uses.
Engineering & selection guide
Bending limits, IP selection, voltage drop, cutting and the full buyer Q&A for this family are kept on the series page.
- Classic SOB dot-free strips — Classic COB LED Strip Light (SOB) — Buyer Questions
- LED strip engineering selection handbook
SOB is the upgraded generation of the COB LED strip
Every SOB board on this page starts from the classic COB recipe — one continuous phosphor line, zero visible dots — and rebuilds it with individually encapsulated, gold-wire-bonded packages soldered on thick copper of up to 105 µm or thicker. The result keeps the COB look while DENO has verified builds up to 24W/m at 24V DC (25 °C ambient, aluminum profile), with a standard binning target of SDCM ≤3; CRI, run length and cut unit are model-specific. For shorter, lower-load or cost-sensitive lines the classic COB range remains a practical choice — compare exact models under equal conditions.
