6060 Lenses LED Strip Light (#8562)
10mm · 12V · 32LEDs · 31.25mm/cut
Model: 8562
Overview
6060 Lenses LED Strip Light | 10mm | 12V | 32LEDs | 31.25mm/cut | #8562 is part of the DENO CCT SMD Strips series, engineered around tunable white LED strip. Key specifications: 6060, 32, 12V, 10 PCB, 2oz copper FPCB, cuttable 1LED/31.25mm, IP20. Every reel is produced on DENO's roll-to-roll line with 99.9% pure copper FPCB and ships CE, UL and RoHS compliant for architectural, retail and hospitality projects. OEM and ODM configurations of length, colour temperature and waterproofing are available on request.
Description
6060 Lenses LED Strip Light | 10mm | 12V | 32LEDs | 31.25mm/cut | #8562 Membrane top is encapsulated with environmental silicon material, which has high light transmittance, reflow light decay, high temperature resistance. and can be reflow soldered to protect the led chip well. It has large-area bracket heat sink, fast heat conduction, and low light decay.
Led Strip With Lens built for smd strips with lenses projects.
Specifications
| LED QTY | 32 |
|---|---|
| PART NO | DL-F60A16V12-Lens-8562-* |
| SMD TYPE | 6060 |
| CUTTABLE UNIT | 1LED/31.25mm |
| DIMMABLE | Yes |
| IP RATING | IP20 |
| LED PITCH | 31.25mm |
| LIFESPAN | 50000 |
| PCB WIDTH | 10 |
| WARRANTY | 5 Years |
| BEAM ANGLE | 160° |
| LENGTH MAX | 5m |
| COPPER FOIL | 2oz |
| POWER RANGE | 3.8~23W |
| CIRCUIT TYPE | C.V. |
| INPUT VOLTAGE | 12V |
| OPERATING TEMPERATURE | -25~40°C;Tc：75°C（max） |
Applications
- Cove, wall-wash & perimeter lighting — Coves, recesses, wall-wash details and ceiling perimeters where a continuous, uniform line of light is required.
- Showroom & hospitality display lighting — Shelving, display cases, reception desks and signage backlighting in shops, showrooms and hospitality spaces.
- Kitchen & wardrobe under-cabinet lighting — Kitchen, wardrobe and furniture task lighting where the strip stays hidden and only the light is seen.
- Hotel & residential tunable-white scenes — Hotel rooms, residential living areas and meeting spaces where warm evening light and neutral daytime light are both required from one fixture.
Request a quotation for #8562
DENO LED is a Shenzhen-based LED strip manufacturer with its own Foshan production base. Send the run length, voltage, CCT/CRI and IP rating you need and our engineering team replies with a specification sheet, wiring plan and price — OEM/ODM and fully custom builds included.
- Warranty: 5 years
- Compliance: CE · UL · RoHS
- Bonding wire: 99.99% pure gold
- Copper foil: 99.9% pure copper FPCB
Photometric Performance — CCT × CRI Efficacy Matrix
Peak measured luminous efficacy: 91.3 lm/W at 4000K, Ra 80, ErP energy class F (Grade DL (2nd Tier) · 12W/m).
All values are measured at the stated power density and ambient 25 °C, reported as luminous efficacy in lumens per watt (lm/W), luminous flux per metre (lm/m) and the corresponding EU ErP (2019/2015) energy class.
Grade DL (2nd Tier) · 12W/m
| CCT (K) | Ra 80 — Luminous Efficacy (lm/W) | Ra 80 — Luminous Flux (lm/m) | Ra 80 — ErP Energy Class | Ra 90 — Luminous Efficacy (lm/W) | Ra 90 — Luminous Flux (lm/m) | Ra 90 — ErP Energy Class | Full Spectrum (Ra 95+) — Luminous Efficacy (lm/W) | Full Spectrum (Ra 95+) — Luminous Flux (lm/m) | Full Spectrum (Ra 95+) — ErP Energy Class |
|---|---|---|---|---|---|---|---|---|---|
| 1800 K | 69.6 lm/W | 834.9 lm/m | G | 55.2 lm/W | 662.9 lm/m | G | — | — | — |
| 2300 K | 77.4 lm/W | 929 lm/m | G | 61.5 lm/W | 738.2 lm/m | G | — | — | — |
| 2700 K | 80.5 lm/W | 965.4 lm/m | G | 66.5 lm/W | 798.5 lm/m | G | — | — | — |
| 3000 K | 87 lm/W | 1044.5 lm/m | F | 70.1 lm/W | 841.1 lm/m | G | — | — | — |
| 3500 K | 88.5 lm/W | 1062.1 lm/m | F | 71.4 lm/W | 856.2 lm/m | G | — | — | — |
| 4000 K | 91.3 lm/W | 1096 lm/m | F | 73 lm/W | 876.3 lm/m | G | — | — | — |
| 5000 K | 91.3 lm/W | 1096 lm/m | F | 73 lm/W | 876.3 lm/m | G | — | — | — |
| 6500 K | 83 lm/W | 995.6 lm/m | G | 70 lm/W | 839.9 lm/m | G | — | — | — |
Grade DL (2nd Tier) · 14.4W/m
| CCT (K) | Ra 80 — Luminous Efficacy (lm/W) | Ra 80 — Luminous Flux (lm/m) | Ra 80 — ErP Energy Class | Ra 90 — Luminous Efficacy (lm/W) | Ra 90 — Luminous Flux (lm/m) | Ra 90 — ErP Energy Class | Full Spectrum (Ra 95+) — Luminous Efficacy (lm/W) | Full Spectrum (Ra 95+) — Luminous Flux (lm/m) | Full Spectrum (Ra 95+) — ErP Energy Class |
|---|---|---|---|---|---|---|---|---|---|
| 1800 K | 68.4 lm/W | 985.1 lm/m | G | 54.3 lm/W | 782.2 lm/m | G | — | — | — |
| 2300 K | 76.1 lm/W | 1096.2 lm/m | G | 60.5 lm/W | 871 lm/m | G | — | — | — |
| 2700 K | 79.1 lm/W | 1139.2 lm/m | G | 65.4 lm/W | 942.1 lm/m | G | — | — | — |
| 3000 K | 85.6 lm/W | 1232.5 lm/m | F | 68.9 lm/W | 992.5 lm/m | G | — | — | — |
| 3500 K | 87 lm/W | 1253.2 lm/m | F | 70.2 lm/W | 1010.3 lm/m | G | — | — | — |
| 4000 K | 89.8 lm/W | 1293.2 lm/m | F | 71.8 lm/W | 1034 lm/m | G | — | — | — |
| 5000 K | 89.8 lm/W | 1293.2 lm/m | F | 71.8 lm/W | 1034 lm/m | G | — | — | — |
| 6500 K | 81.6 lm/W | 1174.7 lm/m | G | 68.8 lm/W | 991 lm/m | G | — | — | — |
Grade DL (2nd Tier) · 19.2W/m
| CCT (K) | Ra 80 — Luminous Efficacy (lm/W) | Ra 80 — Luminous Flux (lm/m) | Ra 80 — ErP Energy Class | Ra 90 — Luminous Efficacy (lm/W) | Ra 90 — Luminous Flux (lm/m) | Ra 90 — ErP Energy Class | Full Spectrum (Ra 95+) — Luminous Efficacy (lm/W) | Full Spectrum (Ra 95+) — Luminous Flux (lm/m) | Full Spectrum (Ra 95+) — ErP Energy Class |
|---|---|---|---|---|---|---|---|---|---|
| 1800 K | 66.1 lm/W | 1269.9 lm/m | G | 52.5 lm/W | 1008.3 lm/m | G | — | — | — |
| 2300 K | 73.6 lm/W | 1413.1 lm/m | G | 58.5 lm/W | 1122.9 lm/m | G | — | — | — |
| 2700 K | 76.5 lm/W | 1468.5 lm/m | G | 63.3 lm/W | 1214.5 lm/m | G | — | — | — |
| 3000 K | 82.8 lm/W | 1588.8 lm/m | G | 66.6 lm/W | 1279.5 lm/m | G | — | — | — |
| 3500 K | 84.1 lm/W | 1615.6 lm/m | G | 67.8 lm/W | 1302.4 lm/m | G | — | — | — |
| 4000 K | 86.8 lm/W | 1667.1 lm/m | F | 69.4 lm/W | 1332.9 lm/m | G | — | — | — |
| 5000 K | 86.8 lm/W | 1667.1 lm/m | F | 69.4 lm/W | 1332.9 lm/m | G | — | — | — |
| 6500 K | 78.9 lm/W | 1514.3 lm/m | G | 66.5 lm/W | 1277.6 lm/m | G | — | — | — |
Related models in this series
See every model in SMD LED Strip Series or narrow to 6060. Compare wattage, lumen output and run length in the ProCalc parameter library, or request OEM/ODM pricing on the custom manufacturing page.
Frequently Asked Questions
What are the key specifications of 8562?
8562: 6060, 32, 12V, 10 PCB, 2oz copper FPCB, cuttable 1LED/31.25mm, IP20. Full photometric data, wiring diagrams and test reports are available in the downloads section of this page.
What colour temperatures and CRI options does this tunable white LED strip offer?
This model is supplied as a tunable white LED strip with high CRI options and the CCT range listed in the datasheet. DENO bins every batch for colour consistency, and custom CCT or spectrum combinations can be produced for project quantities.
Can DENO customise this tunable white LED strip for a project?
Yes. DENO manufactures the CCT SMD Strips series as an OEM and ODM supplier: reel length, colour temperature, CRI grade, PCB width, waterproofing and private labelling can all be specified. Request a quote for lead time and project pricing.
When is a lens LED strip better than a strip with a diffuser?
A diffuser spreads light and loses output, while a lens redirects it. Use a lens LED strip with a 15 or 30 degree beam when light must travel down a tall wall, a deep shelf or a narrow slot, and use asymmetric optics for even wall washing from a close mounting position.
How does a tunable white LED strip mix colour temperature?
Two LED channels, typically 2700K and 6500K, sit on the same FPCB and are dimmed against each other. Mixing the channels sweeps the white point along the black body line while total output stays even, which is how a CCT LED strip supports circadian and human centric lighting schedules.
