8mm | 24V | 120LEDs | 50cut | #2175 | 3528 Classic LED Strip Light
Model: 2175
Overview
The DENO LED Model 2175 3528 Classic LED Strip Light is a versatile and robust lighting solution for various B2B commercial and architectural applications. Featuring a pure copper strong LED frame and 99.9% pure golden wire encapsulation, it ensures enhanced durability and resistance to damage. With an input voltage of 24V, a luminous flux of 1000 lm/m, and a CRI of Ra≥80, it delivers excellent light quality. Its dimmable functionality and wide CCT range (2700-6500K) offer...
Description
8mm | 24V | 120LEDs | 50cut | #2175 | 3528 Classic LED Strip Light Adopt pure copper strong LED frame,99.9% purity diameter> 1 mm pure golden wire encapsulation, can reduce the LED damage in different applications.
Specifications
| cct | 2700-6500 |
|---|---|
| cri | Ra≥80 |
| sdcm | < 3 SDCM (Single Bin) |
| ledQty | 120 |
| partNo | DL-F35A60V24-2175-* |
| smdType | 3528 |
| cuttable | 6LEDs/50mm |
| dimmable | Yes |
| ipRating | IP20/IP65/IP67/IP68 |
| ledPitch | 8.3mm |
| lifespan | 50000 |
| pcbWidth | 8mm |
| warranty | 5 Years |
| beamAngle | 120° |
| lengthMax | 5m |
| copperFoil | 2 oz |
| onOffTimes | 10000（test times） |
| circuitType | CV |
| inputVoltage | 24V |
| luminousFlux | 1000 lm/m |
| minBendDiameter | Φ60mm |
| operatingTemperature | -25~40°C;Tc: 75°C (max) |
Frequently Asked Questions
What are the key electrical specifications for the 2175 LED strip?
The 2175 LED strip operates at 24V, features 120 LEDs/meter, and is cuttable every 50mm. It consumes up to 1000 lumens/meter.
Can this 3528 LED strip be used in outdoor or wet locations?
Yes, the 2175 strip is available with IP65, IP67, and IP68 ratings, making it suitable for various outdoor and wet environment installations.
What is the color rendering index (CRI) and color temperature range for this product?
This 3528 LED strip boasts a high CRI of Ra≥80, ensuring accurate color rendition. It supports CCTs from 2700K to 6500K.
Is bulk ordering and customization available for the DENO LED 2175 model?
Yes, DENO LED offers customizable solutions and competitive pricing for bulk orders of the 2175 strip to meet specific project demands.
