DL-FCN25
Model: DL-FCN25
Overview
The DL-FCN25 is a high-performance Neon LED Strip Series designed for diverse B2B lighting applications. Featuring San’an Chip/Epistar Chip light sources and a unique optical distribution structure using high-transmittance silicone, it delivers excellent light efficacy. With an IP65 waterproof rating and robust environmental characteristics like UV and corrosion resistance, it’s suitable for demanding environments. Its bendable, moldable design allows for creative shapes in...
Description
DL-FCN25 Light source: San’an Chip/Epistar Chip with high luminous efficiency, LM80 test certification. Process material: Unique optical distribution structure design, using high transmittance, high purity silicone material, Light efficacy of white light 50~100lm/W. Waterproof level: IP65 protection level. Appearance design: In addition to metal accessories, you can also choose a mold integrated molding structure to achieve no dark areas at the head and tail. Plastic molding: Bendable, moldable, etc. to create different shapes, including straight lines, circles, arcs, and irregular shapes. Product certification: ETL, CE, ROHS. Environmental characteristics: Salt solution resistant, acid and alkali resistant, corrosion resistant, flame retardant, UV resistant. Operating/Storage Temperature: Ta: -25~55°C / 0~60°C.. Product application: Office lighting, decorative lighting, art lighting, shaping contrast.
Specifications
| ledQty | ≥ 128 LEDs/m |
|---|---|
| partNo | DL-FCN25 |
| cuttable | 8LEDs/62.5mm |
| dimmable | Yes |
| lifespan | 50000h |
| pcbWidth | 10(2PCS) |
| warranty | 5 Years |
| beamAngle | 360° |
| lengthMax | 5m |
| inputVoltage | DC24V |
| operatingTemperature | -25~40°C;Tc：75°C（max） |
Frequently Asked Questions
What are the key technical specifications of the DL-FCN25 Neon LED Strip?
The DL-FCN25 features ≥ 128 LEDs/m, an IP65 rating, DC24V input, a 50,000h lifespan, and a 360° beam angle for versatile applications.
Can the DL-FCN25 Neon LED Strip be used in outdoor or harsh environments?
Yes, with an IP65 rating and strong resistance to salt solution, acids, alkalis, corrosion, and UV, it's ideal for challenging outdoor conditions.
What certifications does the DL-FCN25 have, ensuring its quality and safety?
The DL-FCN25 is proudly certified with ETL, CE, and ROHS, assuring its compliance with major industry quality and safety standards.
Is custom molding or specific lengths available for the DL-FCN25 product?
Yes, the DL-FCN25 is bendable and moldable to create various shapes. Please contact us for custom length and design requirements.
