DL-F50A98V24-16795-*
Model: 16795
Overview
The DENO LED model 16795 is a state-of-the-art flexible LED panel, an advanced lighting solution designed for a wide range of B2B applications. This panel mixes RGBW 4-chip-in-1 LEDs, offering an unparalleled color palette with up to 4 billion tunable colors, including a soft pastel range. Its LED light sheet design is perfect for creating large-area surface lighting and is backed by an efficient heat dissipation system for long-term stability. Ideal for backlighting, archi...
Description
DL-F50A98V24-16795-* Mixes RGBW 4 chip in 1 LED, with tunable fucntion combine. Up to 4 billion colors to choose from. With the addition of white light, much brighter colors and a softer pastel range are produced to satisfy the exacting color requirements of any lighting design. LED light sheet design, suitable for creating large-area surface lighting. Efficient heat dissipation design, ensuring long-term stable operation. Ideal for backlighting, architectural lighting, advertising displays, and stage lighting applications.
Specifications
| ledQty | 98 LEDs/sheet |
|---|---|
| partNo | DL-F50A98V24-16795-* |
| smdType | 5050 |
| cuttable | 7LEDs/34.286*240mm |
| dimmable | Yes |
| ipRating | IP20 |
| ledPitch | 34.286mm |
| lifespan | 50000 |
| pcbWidth | 240mm |
| warranty | 5 Years |
| beamAngle | 120° |
| lengthMax | 4pcs |
| copperFoil | 2oz |
| powerRange | 12~26.8W |
| circuitType | CV |
| inputVoltage | DC 24V |
| operatingTemperature | -25~40°C;Tc：75°C（max） |
Frequently Asked Questions
What are the primary applications for the 16795 Flexible LED Panel?
The 16795 Flexible LED Panel is primarily used for backlighting, architectural lighting, advertising displays, and stage lighting applications due to its versatile RGBW tunable capabilities.
What color control and brightness options does this panel offer?
This panel features RGBW 4-chip-in-1 LEDs, offering up to 4 billion tunable colors. The addition of white light produces brighter colors and a softer pastel range.
What are the input voltage and environmental ratings for the 16795 model?
The 16795 operates on DC 24V input voltage. It has an IP20 rating and an operating temperature range of -25~40°C, suitable for indoor environments.
What is the typical lifespan and warranty for this DENO LED product?
The 16795 Flexible LED Panel has a long lifespan of 50,000 hours. DENO LED provides a comprehensive 5-year warranty for this product.
