10x10mm V Shape Aluminum Channel LED
Model: DL-1010HX-V
Overview
The DENO LED DL-1010HX-V is a premium V Shape Aluminum Channel LED, meticulously engineered for optimal heat dissipation, extending the lifespan of LED strips. Its unique V-profile design casts light at an ideal 30°-45° angle, perfect for creating inviting indirect illumination in various settings. This durable aluminum profile is corrosion-resistant and suitable for both sophisticated residential and demanding commercial environments. With easy installation and support for...
Description
10x10mm V Shape Aluminum Channel LED Superior Heat Dissipation: The V Shape Aluminum Channel LED acts as a heatsink, extending LED lifespan by preventing overheating. The V-shaped aluminum profile directs light at an optimized 30°–45° angle toward walls or countertops, creating soft indirect illumination and enhancing the overall spatial atmosphere. Sleek & Durable: Its robust aluminum construction resists corrosion and aging, perfect for both elegant homes and demanding shops. Easy Installation: Designed for quick and secure mounting, saving you time and effort on any project. High Efficiency: Enables brighter, more consistent light while supporting energy-saving high-power LED strips.
Specifications
| sdcm | < 3 SDCM (Single Bin) |
|---|---|
| ledQty | 120leds/m or above |
| partNo | DL-1010HX-V |
| smdType | 1515 |
| cuttable | 1LED/3.333mm |
| dimmable | Yes |
| ledPitch | 3.333mm |
| pcbWidth | 5mm |
| warranty | 5 Years |
| lengthMax | 0.5~3m |
| copperFoil | 2oz |
| circuitType | CV |
| inputVoltage | DC 24V |
| operatingTemperature | -25~40°C;Tc：75°C（max） |
Frequently Asked Questions
What is the primary benefit of the V shape aluminum channel for LED strips?
The V shape aluminum channel acts as an efficient heatsink, significantly improving heat dissipation and extending the lifespan of the LED strips by preventing premature failure.
What are the common applications for the DL-1010HX-V aluminum profile?
This profile is ideal for creating indirect lighting effects on walls, under cabinets, or along countertops in commercial, retail, hospitality, and residential projects.
Is the DL-1010HX-V compatible with standard LED strip voltages?
Yes, the DL-1010HX-V is designed to be compatible with popular DC 24V LED strips, ensuring versatile integration into existing lighting systems.
Can this aluminum channel be cut or customized to specific lengths?
Yes, the DL-1010HX-V can be ordered in custom lengths ranging from 0.5m to 3m, allowing for precise adaptation to project requirements.
